10.4 Multiple Instruction Issue (Supers alar) Machines – The PowerPC 601
In the earlier pipelining discussion, we see how several instructions can be in various phases of execution at once. Here, we look at superscalar architecture, where, with separate execution units, several instructions can be executed simul-
taneously. In a superscalar architecture, there might be one or more separate Integer Units (IUs), Floating Point Units (FPUs), and Branch Processing Units (BPUs). This implies that instructions need to be scheduled into the various execution units, and further, that instructions might be executed out-of-order.
Out-of-order execution means that instructions need to be examined prior to dispatching them to an execution unit, not only to determine which unit should execute them, but also to determine whether executing them out of order would result in an incorrect program, because of dependencies between the instructions. This in turn implies an Instruction Unit, IU, that can prefect instructions into an instruction queue, determine the kinds of instructions and the dependence relations among them, and schedule them into the various execution units.
10.5 Case Study: The PowerPC™ 601 as a Superscalar Architecture
As an example of a modern superscalar architecture let us examine the Motorola PowerPC™ 601. The 601 has actually been superseded by more powerful members of the PowerPC family, but it will serve to illustrate the important features of superscalar architectures without introducing unnecessary complexity into our discussion.
10.6.1 INSTRUCTION SET ARCHITECTURE OF THE POWERPC 601
The 601 is a 32-bit general register RISC machine whose ISA includes:
• 32 32-bit general purpose integer registers (GPRs);
• 32 64-bit floating point registers (FPRs);
• 8 4-bit condition code registers;
• nearly 50 special-purpose 32-bit registers that are used to control various aspects of memory management and the operating system;
• over 250 instructions (many of which are special-purpose).
10.6.2 HARDWARE ARCHITECTURE OF THE POWERPC 601
Figure 10-12, taken from the Motorola PowerPC 601 user’s manual, shows the microarchitecture of the 601. The flow of instructions and data proceed via the System Interface, shown at the bottom of the figure, into the 32KByte cache. From there, instructions are fetched eight at a time into the Instruction Unit, shown at the top of the fiture.The issue logic within the Instruction Unit examines the instructions in the queue for their kind and dependence, and issues them into one of the three execution units: IU, BPU, or FPU.
The IU is shown as containing the GPR file and an integer exception register, XER, which holds information about exceptions that arise within the IU. The IU can execute most integer instructions in a single clock cycle, thus obviating
the need for any kind of pipelining of integer instructions.
The FPU contains the FPRs and the floating point status and control register (FPSCR). The FPSCR contains information about floating point exceptions and the type of result produced by the FPR. The FPU is pipelined, and most FP instructions can be issued at a rate of one per clock.
As we mentioned above in the section on pipelining, branch instructions, especially conditional branch instructions, pose a bottleneck when trying to overlap instruction execution. This is because the branch condition must first be ascertained to be true, for example “branch on plus” must test the N flag to ascertain that it is cleared. The branch address must then be computed, which often involves address arithmetic. Only then can the PC be loaded with the branch address.
The 601 attacks this problem in several ways. First, as mentioned above, there are eight 4-bit condition code registers instead of the usual one. This allows up to eight instructions to have separate condition code bits, and therefore not interfere with each other’s ability to set condition codes. The BPU looks in the instruction queue, and if it finds a conditional branch instruction it proceeds to compute the branch target address ahead of time, and fetches instructions at the branch target. If the branch is taken, this results in effectively a zero-cycle branch, since the instruction at the branch target has already been fetched in anticipation of the branch condition being satisfied. The BPU also has a link register (LR) in which it can store subroutine return addresses, thus saving one GPR as well as several other registers used for special purposes. Note that the BPU can issue its addresses over a separate bus directly to the MME and Memory unit for prefetching instructions.
The RTC unit shown in the figure is a Real Time Clock which has a calendar range of 137 years, with an accuracy of 1 ns.
The MMU and Memory Unit assist in fetching both instructions and data. Note the separate path for data items that goes from the cache directly to the GPR and FPR register files.
The PowerPC 601, and its more powerful descendants are typical of the modern general purpose microprocessor. Current microprocessor families are superscalar in design, often having several of each kind of execution unit.
